The BEFARD XS vacuum gripper is a device installed on the hook of any lifting device, designed to transfer sheets, plates and worktops to cutters and storage racks. The BEFARD XS 1080 model allows to grip loads with a maximum weight of 1080 kg.
Download the device data sheet:
XS_PRODUCT_DATA_SHEET.pdf1.76 MB
Power supply from the mains Horizontal working is available Gripping of any material sheets Quick fastening and removal of cargo Reduced costs and increased safety 12 x Ø 310 mm suction cups (manual distance adjustment) Specification:
BEFARD XS 1080 Number of suction cups 12 pieces Size of suction cups Ø 310 mm Vacuum system single circuit Min/max vacuum -0,6 / -0,8 bar Power supply from the mains Hoist capacity 1080 kg The device meets the requirements of the Machinery Directive 2006/42/EC and Directive 2014/30/EU
All BEFARD devices are covered by a 12-month warranty.
