BEFARD XJ 105

The BEFARD XJ TRAILER CRANE is a modern solution used for material handling. It is compatible with various types of grippers and can be used both for handling as well as for and assembly of sandwich panels and glass.

The device is completely self-contained and independent. It has its own power supply from the internal combustion engine. BEFARD XJ 105 with a range of almost 19.0 m and a lifting capacity of max. 2500kg.

Due to its weight, the trailer can be towed by virtually any delivery vehicle, and it also has two braked axles.

Download the device data sheet:

pdfBEFARD_XJ_105_TRAILER_CRANE.pdf5.35 MB

Specification:

registered for full hoist capacity
maximum hoist capacity 2500 kg
maximum vertical range of almost 19.0 m
extension fitted with textolite slides
crane made of WELDOX 700 Swedish steel
combustion power supply - diesel engine + 230V from the mains
optional alternative power supply - Li-ion batteries
radio remote control
trailer GVW 3500kg

The device meets the requirements of the Machinery Directive 2006/42/EC and Directive 2014/30/EU

All BEFARD devices are covered by a 12-month warranty.

Diagramy udzwigu XJ 105 STANDARDHAK.IIDiagramy udzwigu XJ 105 JIB OSPRZET.II
